k-means clustering partitions n observations into k clusters in which each observation belongs to the cluster with the nearest mean.

Here we're implementing a heuristic algorithm for k-means clustering.

We have N points that we want to partition into K clusters.

It works this way:

- Pick K random points from the N points.
- Assign each of the other N-K points to a cluster $ C_i $ where "i" is the index of the closest point from the K points selected above.

Repeat until no changes:

- For each cluster, compute its mean.
- Iterate over all N points and assign each one to a cluster indexed by the closest mean.

This is displayed and inplemented below:

In [1]:

```
import random
import numpy as np
import matplotlib.pyplot as plt
def plot_points(title, use_colors=True):
xs = [p[0] for p in points]
ys = [p[1] for p in points]
assert(len(xs) == N)
if use_colors:
colors = [(cc / float(K)) for cc in cluster]
plt.scatter(xs, ys, edgecolors='none', s=30, c=colors)
else:
plt.scatter(xs, ys, edgecolors='none', s=30)
plt.title(title)
plt.show()
# Number of points.
N = 720
# Number of clusters.
K = 6
points = []
for i in range(0, N):
x = random.randint(0, 100)
y = random.randint(0, 100)
points.append((x, y))
plot_points('Initial %d points which we\'ll split into %d clusters.' % (N, K), use_colors=False)
```

In [2]:

```
cluster = [-1] * N
indices = range(0, N)
random.shuffle(indices)
mean_point_idxs = indices[0: K]
for i in range(0, K):
cluster[ mean_point_idxs[i] ] = i
for idx in range(0, N):
if idx not in mean_point_idxs:
# Find closest.
ci = -1
mindistance = 1 << 30
for i in range(0, K):
cm = mean_point_idxs[i]
distance = (points[idx][0] - points[cm][0]) ** 2 + (points[idx][1] - points[cm][1]) ** 2
if distance < mindistance:
mindistance = distance
ci = i
cluster[idx] = ci
plot_points('Initial cluster assignment.')
```

In [3]:

```
for iter in range(0, 50):
# Compute mean for every cluster.
sumx = [0.0] * K
sumy = [0.0] * K
totals = [0] * K
for i in range(0, N):
sumx[ cluster[i] ] += points[i][0]
sumy[ cluster[i] ] += points[i][1]
totals[ cluster[i] ] += 1
# Compute new means.
meanx = [0] * K
meany = [0] * K
for i in range(0, K):
meanx[i] = sumx[i] / totals[i]
meany[i] = sumy[i] / totals[i]
# Create new clusters.
new_cluster = [0] * N
for i in range(0, N):
mindist = 1 << 30
for j in range(0, K):
dist = (points[i][0] - meanx[j]) ** 2 + (points[i][1] - meany[j]) ** 2
if dist < mindist:
mindist = dist
cluster_idx = j
new_cluster[i] = cluster_idx
if cluster == new_cluster:
print 'DONE'
break
else:
moved = 0
for i in range(0, N):
if cluster[i] != new_cluster[i]: moved += 1
print 'MOVED =', moved
cluster = new_cluster
plot_points('Clusters after iteration %d' % (iter+1))
```
